Terry Burris brought his 23 T Bucket 393 Stroked Cleveland Street Rod in for tunning. The car is equipped with a C6 transmission and Ford 9 inch axle through the mufflers. The baseline pull was 381 RWHP. After a session on the dyno Jim improved upon that to the tune of 429 RWHP with only 28 degrees of timing on 93 octane pump gas. That was accomplished with a tune kept conservative to prevent detonation in hot weather.
Check out the video:
Monday, October 11, 2010
Magazine Clips from 1992 Archives
Back in mid/late 1991 Turbo Connection was just getting started. Here's a few clips from the archives that appeared in the Jan 1992 issues of "Mustangs and Fords" and "Turbo and High Tech" Magazines. It featured a totally stock notchback other than a Turbo Engineering Turbo Kit and Jims "wizardry" ran an astounding 11.33 at 124 MPH! When we say STOCK we mean STOCK! Stock throttle body 19 lb injectors YES 19 lb injectors rockers EVERYTHING!
99 Vette D1SC 402 Cranks Out 688 RWHP on E85 runs nines at the track!
Matt has been a customer of ours for some time now. Several years ago we installed an ATI D1SC Procharger on his otherwise stock setup other than headers exhaust and high stall converter. It cranked out 515 RWHP with the stock converter and 490 RWHP with built trans, high stall converter and 9 psi boost. The all stock engine ran 11.20's at 124 MPH back then. Over the past several months he's installed a built 9 to 1 CR 402 and brought it to Jim for tuning, several mechanical/electrical issues, and debugging. When it arrived it would hardly run and sounded like a prostock at idle. Jim spent several days working out the mechanical/electrical issues and then kinks in the tune. He had the car idling with just a "slight lope" at idle(quite a feat considering how healthy the cam used was) and silky smooth driveability from off idle through redline! It cranked out 622 RWHP on 93 octane fuel with meth injection. Then s few weeks ago the old alky kit started acting up so Matt contacted Jim for a better solution. Jim told him that he has made tremendous gains on E85 fuel and optimized tune. Matt gave Jim the nod and the vette was upgraded from 60 lb injectors to a set of 80 lb injectors then revamped/optimized tune via HP Tuners software. After several days of tweaking the car made 688 RWHP with just 10 psi boost! When Matt picked up the car, Jim told him it was a handful on the street, that the car would go nines in the quarter but that it would probably need slicks to get the power to the ground. Matt's a veteran racer and based on the dyno numbers and fully loaded weight of Vette he agreed. On Tuesday Oct 5th Matt took it to Gateway International Raceway and found the track to really be hooking up. On his full out pass the Vette ran 1.66 60 ft 9.95 sec at 142.34 MPH in 1/4 mile on DRAG RADIALS! Congrats Matt! Check out the dyno pull and quarter mile pass below:
Saturday, February 6, 2010
Turbo Connection Racing's 1500 RWHP GTO Twin Turbo Setup
Click photos below for exploded views:
On July 15, 2010 with 21 psi boost on E85 fuel we exceeded 1300 SAE rear wheel horsepower! Using an industry standard 15% driveline loss thats an estimated 1495 engine/flywheel horsepower! More to come!
Latest Revisions:
On July 15, 2010 with 21 psi boost on E85 fuel we exceeded 1300 SAE rear wheel horsepower! Using an industry standard 15% driveline loss thats an estimated 1495 engine/flywheel horsepower! More to come!
Latest Revisions:
Friday, September 4, 2009
Jeff Leutz Awesome 540 EFI BBC
The pictures of this ride speak for themselves. this 540 inch BBC was built by legend Gary Duckworth from Maryville Illinois. Much of the detail wand work was performed by owner Jeff Leutz. It features a Mass Flow EFI system that will soon be upgraded with a polished throttle body bonnet from procharger, polished 3.5 inch aluminum tubing and high flow Pro M Velocity mass air meter with PMS tuned by Jim Riskovsky Jr. Click on pictures below for an exploded view:
John Wilmeshires 04 Supercharged GTO lays down 551 RWHP 565 RWTQ
John brought his 2004 Maggie equipped "forged 5.7 liter" GTO to us for the installation of a Finish Line Performance transmission and stall, remote mounted external transmission oil cooler, SCSS AEM wide band, oil pressure and transmission temperature gauges, Lonnies Performance 1000 HP twin fuel pump upgrade kit, Lakewood driveshaft loop, 800 HP G Force Axles, BMR Driveshaft, Harrop girdle, DBX 97 mm Mass air meter, Ron Davis Radiator, 65 lb injector upgrade and custom tuning. Can ran 10.89 at 128 MPH a week after it left the shop!!!! Below are some photos and the dyno video.
Tuesday, July 28, 2009
Alex Pearse's 91 Procharged 331 Makes 784 RWHP @ 16 psi through the mufflers!!!!
Alex Pearse's 91 Mustang GT features a state of the art 331 inch stroker short block with D1SC Procharger tuned and built at Turbo Connection Racing by Jim Riskovsky Jr. Next on the agenda is a switch to E85 fuel and a return trip to the dyno. Check out the dyno vid below:
Scott Hensley Receives Best Of Show Award!!
We are pleased to announce that one of our customers recieved a Best Of Show Award with his 2006 Pontiac GTO Sunday July 26, 2009! He also received an invite to an upcoming Best Of Show recipient Car show.
Friday, October 17, 2008
2006 Procharged GTO 676 RWHP 686 RWTQ
This 2006 features a cast iron 6.0 liter all forged 9.7 to 1 short block topped off with Livernois Motorsports Stage 2 CNC ported L92 heads, a 211 230 @ .050 on a 120.5 LSA .554 int .588 exh hydraulic roller cam. Kooks long tube headers with Quicktime 3 inch exhaust cutouts. 65 lb fuel injectors, twin lonnies performance fuel pump upgrade, F1A Procharger 15 psi boost. Driveshaft shop 1000 RWHP axles ad spool, and BMR aluminum driveshaft. CK Performance 4L80 transmission with trans brake and 3500 stall lockup converter. Custom gauges, wheels and paint. On pump gas, with SMC alky injection kit, through the cats she made a respectable 676 RWHP 686 RWTQ first time on the rollers! Click on pictures below for an exploded view:
Turbo Connection Racing Twin Turbo GTO On the Cover of "Engine Builder Magazine" Sept 2008 Issue
Click Links Below to Read The Full Article and LS1GTO forum info:
http://www.enginebuildermag.com/Content/Site302/SpecialIssue/11_01_2008/3789429GMpdf_00000011833.pdf
Monday, April 14, 2008
1028 RWHP 1998 Twin Turbo Mustang Cobra
A tremendous amount of time have gone into detailing the engine bay. Look closely and you'll notice that the coils have been moved to the firewall, fuel system has been upgraded with Aeromotive fuel rails, 160 lb injectors, and power coated intake,valve covers, timing cover and so much more!! Final revisions were upgraded block and liters to 5.3 along with GT 500 heads. Coils now relocated and hidden under the intake manifold. Engine makes 1028 RWHP 1097 RWTQ on E85! Stay tuned!!!
ENGINE APPEARANCE COMPARTMENT WHEN IT SHOWED UP AT OUR FACILITY
ENGINE COMPARTMENT APPEARANCE AFTER "FIRST" REVISION
FINAL REVSIONS NOW UPGRADED TO 5.3 LITER AND GT500 HEADS
Sunday, March 30, 2008
1200 PLUS Rear Wheel Horsepower 70 512 BBC Turbo Monte Carlo
A few months ago this 70 Monte Carlo showed up for a tuning session. During the course of the day, we went from 900 rear wheel horsepower with 5 psi boost to 1200 PLUS rear wheel horsepower at 15 psi boost! That translates to 1600 PLUS engine horsepower!!!! What makes this especially extraordinary, is it was accomplished on 110 Octane race fuel WITHOUT an intercooler!! The car features a 512 inch Big Block Chevy with conventional 23 degree heads, single plane intake, 850 custom blow thru carb and hat, Boost Cooler alky injection kit, custom solid roller cam, custom turbo headers with a single Precision Turbo PT106 Turbocharger. Power is transferred through a custom build Turbo 400 transmission with trans brake into a narrowed and tubbed Ford 9 Inch rear axle and 4 link suspension.
Saturday, March 29, 2008
802 Rear Wheel Horsepower 66 Chevelle 406 Small Block
This 66 Chevelle was brought to us from North Indiana for tuning. Chad had heard about us through word of mouth and several internet posts on our company 2005 Procharged GTO. Chad's Chevelle features Canfield Heads, 8.5 compression forged small block chevy with healthy solid roller, 850 blow thru carb, alky control injection running on 110 octane race fuel with 16 psi boost. After several key issues were addressed it was time to strap her down to the dyno and make some power. Chad's previous best was 560 rear wheel horsepower. Working with jetting, timing, alky mixture and volume flow rates, performing air inlet upgrades, and an aluminum twin disk clutch upgrade, we proceeded to walk the power up to an astounding 802 horsepower at the wheels THROUGH THE MUFFLERS!!! Based on typical parasitic drag information thats 1000 engine horsepower folks!!!
